The Story
The LC-241 brushless DC motor controller allows for 100% duty cycle control of a brushless DC linear actuator. Using the control inputs, the user has full control over the speed and direction of a brushless DC actuator. Our PA-14 and PA-14P linear actuators can be customized to have a brushless DC motor to function with the LC-241 controller.
Using the screw terminals, connect the linear actuators to the control box. Apply 12-24VDC across the power wires and follow the control integration information which can be found in the LC-241 User Manual.
It is important to ensure that the power supply has a sufficient amperage rating to control the linear actuators. The LC-241 is designed to control a maximum 8A, 12-24VDC brushless DC linear actuator.
* Only compatible with customized PA-14 and PA-14P brushless motors (12 or 24 VDC). Not compatible with standard brushed motors.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
The LC-241 brushless DC motor controller allows for 100% duty cycle control of a brushless DC linear actuator. Using the control inputs, the user has full control over the speed and direction of a brushless DC actuator. Our PA-14 and PA-14P linear actuators can be customized to have a brushless DC motor to function with the LC-241 controller.
Using the screw terminals, connect the linear actuators to the control box. Apply 12-24VDC across the power wires and follow the control integration information which can be found in the LC-241 User Manual.
It is important to ensure that the power supply has a sufficient amperage rating to control the linear actuators. The LC-241 is designed to control a maximum 8A, 12-24VDC brushless DC linear actuator.
* Only compatible with customized PA-14 and PA-14P brushless motors (12 or 24 VDC). Not compatible with standard brushed motors.
